PRV Audio 12MR2000 12" Midrange Loudspeaker
Free Shipping
Free standard shipping to Contiguous 48 US States
Free Returns
Learn More.
Features
Highlights
- Nominal Impedance: 8 Ohm
- Nominal Power Handling: 1000 Watts
- Continuous Program Power (RMS): 2000 Watts
- Sensitivity (1W/1m): 97 dB
- Voice Coil Diameter: 4?
GENERAL SPECIFICATIONS
| Nominal Diameter | 12? (305 mm) |
| Nominal impedance | 8 Ohm |
| Nominal Power Handling* | 1000 Watts |
| Continuous Program Power (RMS)** | 2000 Watts |
| Max Peak Power*** | 4000 Watts |
| Sensitivity 2.83V at 1m | 97 dB |
| Recommended Hi Pass Crossover For Full Power Handling |
145 Hz 12db Per Octave Crossover |
| Frequency Response | 72 5,000 Hz |
| Voice Coil Diameter | 4? (101 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Winding Depth | 17.0 mm |
| Former Material | Aluminum |
| Magnetic Gap Depth | 7.5 mm |
| Frame Material | Die Cast Aluminum |
*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.
THIELE-SMALL PARAMETERS
| Equivalent Volume | Vas | 52.52 l |
| Excursion (mathematical)*** | Xmax | 6.62 mm |
| Free Air Resonance | Fs | 57.23 Hz |
| Mechanical Factor | Qms | 23.84 |
| Electrical Factor | Qes | 0.34 |
